Meet the TYPHON TERROR LXV — 14,500 pounds of engineered intent, built for the kind of work that doesn’t make headlines but holds everything up. This isn’t a backyard mini excavator. This is the 6.6-ton compact excavator that foundation crews, land developers, municipal operators, and serious contractors have been waiting for.
━━━━━━━━━━━━━━━━━━━━━━━━━━
━━━━━━━━━━━━━━━━━━━━━━━━━━━
📐 MACHINE SPECIFICATIONS
OVERALL DIMENSIONS
Operating Weight: 14,500 lbs (6.6 tons)
Length: 19′ 2″
Width: 6′ 7″
Height: 8′ 5″
ENGINE
Engine: Kubota V2607 Diesel
Power: 56.9 HP @ 2700 RPM
Cylinders: 4-Cylinder | Water-Cooled
Idle Speed: 825–875 RPM
Bore & Stroke: 3.43″ × 4.33″
Fuel Tank: 8 Gallons
Hydraulic Oil Tank: 10.8 Gallons
Certification: EPA Tier 4
WORKING RANGE
Max Digging Depth: 11′ 6″
Max Digging Height: 16′ 11″
Max Unloading Height: 12′ 1″
Boom Swing System
360° Body Rotation
HYDRAULIC SYSTEM
Piston Pump
Load-Sensing Technology
Multi-Way Control Valve
Multi-Function Simultaneous Operation
Strong Hydraulic Output for Attachments
OPERATOR STATION
Twin Pilot Joystick Controls
Enclosed AC/Heater Cabin
High/Low Travel Speed Control
360° Body Rotation
Reinforced Steel Base
Heavy-Duty Steel Track System
━━━━━━━━━━━━━━━━━━━━━━━━━━━
🔥 KEY FEATURES
✅ EPA Tier 4 Certified Kubota V2607 Engine — clean, reliable, compliant power
✅ Compact Footprint — fits where bigger machines cannot
✅ Boom Swing System — dig past obstacles without repositioning
✅ 360° Body Rotation — work every angle from a single setup
✅ Twin Pilot Joystick Controls — precision in every motion
✅ Load-Sensing Hydraulics — flow matches workload in real time
✅ Multi-Way Control Valve — simultaneous multi-function operation
✅ Fully Enclosed AC/Heater Cab — year-round operator comfort
✅ Heavy-Duty Steel Tracks — built to absorb punishment
✅ Reinforced Steel Base — engineered to endure
✅ High/Low Travel Speed Control — adapt to any terrain
✅ Strong Hydraulic Output — runs every attachment in your arsenal
