The TYPHON STOMP V1000 Skid Steer is a compact yet powerful 1.5-ton machine designed for tight spaces, demanding tasks, and maximum productivity across construction, landscaping, and agricultural applications.
With its compact footprint, the V1000 easily operates in narrow areas where larger machines cannot, while its versatile attachment system allows it to dig, lift, drill, level, break, and clean up efficiently.
🔧 Key Specifications:
✔ Operating Weight: 1.5 Ton (1500 kg)
✔ Engine: Kubota D1105-E4 Diesel
✔ Power Output: 24.4 HP (18.2 kW @ 3000 rpm)
✔ Rated Operating Capacity: 780 kg (1,720 lbs)
✔ Hydraulic Flow: 33–48 L/min
✔ Working Pressure: 18 MPa
✔ Lift Height: 2852 mm
✔ Travel Speed: 4.5 km/h
✔ Fuel Tank: 20 L
✔ Hydraulic Oil Tank: 22 L
✔ Width: 980 mm
✔ Length: 3000 mm
✔ Height: 1530 mm
⚙️ Core Features:
✔ Compact Design (980 mm width) — perfect for tight access areas
✔ 360° Maneuverability — smooth turning in confined spaces
✔ Low Ground Pressure (24 kPa) — stable on soft or muddy terrain
✔ 30° Climbing Ability — handles slopes with confidence
✔ Quick-Swap Attachments — switch tools fast, reduce downtime
✔ Hydraulic Pilot Controls — smooth, precise operation
✔ Load-Sensing Hydraulic System — efficient power distribution
✔ LED Work Lights — clear visibility in all conditions
✔ Reinforced Frame — built for durability and long-term use
🔄 Attachments & Versatility:
The STOMP V1000 supports a wide range of attachments including:
- Augers (drilling)
- Breakers (demolition)
- Grapples (material handling)
- Trenchers (utility work)
- Sweepers (site cleanup)
This makes it a true multi-purpose machine for different industries.
🚧 Applications:
The V1000 performs efficiently in:
- Landscaping and backyard projects
- Residential construction sites
- Farming and agricultural work
- Warehouse material handling
- Urban and tight-space jobs
💪 Why Choose STOMP V1000?
- Compact size with high power output
- Reliable Kubota diesel engine
- Multi-tasking capability with attachments
- Easy operation for beginners and professionals
- Built for durability, efficiency, and performance
The TYPHON STOMP V1000 Skid Steer is designed to help you work faster, reduce manual labor, and increase productivity on every job site.
