TYPHON TERROR XVII PRO Prestige Edition
4,000 lb Enclosed Mini Excavator
EPA Certified Kubota D902
Fully Enclosed AC + Heater Cabin
Dual Auxiliary Hydraulics
14 kN Digging Force
The TYPHON TERROR XVII PRO Prestige
Edition is the professional-grade
enclosed compact mini excavator built
for contractors, operators, and builders
who demand performance that does not
stop when conditions get difficult.
Rain. Heat. Cold. Dust.
The Prestige Edition works through
all of it — from inside a fully
enclosed climate-controlled cabin
with AC and heater built in as standard.
EPA certified Kubota D902 engine.
High-pressure dual auxiliary hydraulic
circuits at 2,610 PSI. Armored hoses
and shielded valves. 14 kN breakout
force. 86.50-inch maximum digging depth.
Dark Cherry Prestige finish.
This is not a standard mini excavator
with a cab added. This is a
purpose-built enclosed professional
machine from the ground up.
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⚙️ ENGINE SPECIFICATIONS
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✅ Engine: EPA Certified Kubota D902
✅ Configuration: Compact Vertical
3-Cylinder
✅ Type: Water-Cooled 4-Cycle Diesel
✅ Power Output: 15.8 HP @ 2,200 RPM
✅ Peak Power: 20.4 HP @ 3,600 RPM
✅ Fuel Tank: 3.17 Gallons
✅ Hydraulic Oil Reservoir: 4.76 Gallons
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🏠 ENCLOSED CABIN SPECIFICATIONS
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✅ Fully Enclosed All-Weather Cabin
✅ AC and Heater — All Seasons
✅ Interior Height: 41.34 Inches
✅ Interior Width: 20.08 Inches
✅ Machine Height: 97.64 Inches
✅ Ergonomic Seat with Premium
Headrest and Armrests
✅ Commanding View of Work Area
✅ Dark Cherry Prestige Exterior
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
💧 HYDRAULIC SYSTEM
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✅ Operating Pressure: 18 MPa | 2,610 PSI
✅ Pilot Flow: 1.82 GPM
✅ Main Hydraulic Flow: 6.07 GPM
✅ Dual Auxiliary Hydraulic Circuits
✅ Oil Cooling Core Protection
✅ Armored Hydraulic Hoses
✅ Shielded Hydraulic Valves
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
⛏️ DIGGING PERFORMANCE
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✅ Digging Force: 14 kN
✅ Maximum Digging Depth: 86.50 Inches
✅ Bucket Width: 16.54 Inches
✅ Bucket Capacity: 0.04 m³
✅ Standard Dozer Blade Included
✅ Hydraulic Thumb Clip Included
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
🚜 MOBILITY AND REACH
━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━━
✅ Boom Swing: 45° Left | 55° Right
✅ Upper Structure: Full 360° Rotation
✅ Track Width: 9.06-Inch Sure-Grip
Rubber Tracks
✅ Travel Speed: 1.30 MPH
✅ Operating Weight: 4,000 lbs
