Meet the TYPHON STOMP X1300 — the mini skid steer loader that doesn’t just fit through your gate. It fits the entire job site into a single machine. Just 35.4 inches wide. Powered by an EPA-certified Kubota D1105 diesel engine. Engineered to swap attachments in seconds.
In this video, we walk you through the complete TYPHON STOMP X1300 system — the machine itself plus every attachment in the lineup. From sunrise tiller work to sunset sweeper cleanup, the X1300 becomes whatever the job demands.
━━━━━━━━━━━━━━━━━━━━━━━━━━━
━━━━━━━━━━━━━━━━━━━━━━━━━━━
📐 MACHINE SPECIFICATIONS
OVERALL DIMENSIONS
Body Width: 35.4″ (900mm)
Vertical Lift Pin Height: 7′ 8″ (2352mm)
Compact footprint for confined spaces
ENGINE
Engine: Kubota D1105 Diesel (EPA Certified)
Power: 25 HP @ 3000 RPM | 19 HP @ 2200 RPM
Cylinders: 3-Cylinder, Water-Cooled, Indirect Injection
Vertical, 4-Cycle Diesel
HYDRAULIC SYSTEM
Italian HANSA Closed-Loop System
IMPRO Motor
Taifeng Plunger Pump (3-Pump Design)
Lufthansa Joystick Controls
Pilot Control (Left) + Mechanical Control (Right)
━━━━━━━━━━━━━━━━━━━━━━━━━━━
🛠️ COMPLETE ATTACHMENT LINEUP
✅ Standard Bucket — scoop, load, haul
✅ 4-in-1 Bucket — dig, doze, grab, spread
✅ Pallet Forks — lift pallets like a forklift
✅ Hydraulic Auger (200mm) — drill perfect post holes
✅ Trencher — cut clean utility line trenches
✅ Hydraulic Hammer Breaker — demolish concrete, asphalt, stone
✅ Rotary Tiller — turn hard ground into planting-ready soil
✅ Land Leveler — finish-grade in a single pass
✅ Brush Cutter — reclaim overgrown land
✅ Stump Grinder — eliminate stumps below grade
✅ Mulcher — reduce trees and brush to mulch
✅ Snow Blower — clear pavement clean in winter
✅ Rock Screening Bucket — separate fine material from coarse
✅ Hydraulic Grapple Bucket — secure loose loads
✅ Wood Grabber / Rotating Log Grapple — grip, rotate, stack logs
✅ Bulldozer Blade — push, grade, and shape ground
✅ Backhoe Digger — excavate deep where buckets can’t reach
